Product Attributes
Supports internal and external two LCD screen display, and the external LCD is one key operation.
Micro-processing chip design to improve the computing speed and stability of the equipment.
LCD display, setting parameters and equipment operating status.
The adjustable mains charging current range is 0-30A.
Working modes: grid priority, inverter priority.
Optional built-in PWM or MPPT solar controller to achieve high-efficiency charging.
Support diesel and gasoline generators, suitable for various grid power.
OEM/ODM
Aрреаrаnce
Colour
Configurable Data
OEM/ODM
Technical Parameters
AC input
Rated Input Voltage:110VAC/120VAC/220VAC/230VAC/240VAC
AC Input Voltage Range:85VAC-138VAC(110VAC)/95VAC-148VAC(120VAC)/170VAC-275VAC(220VAC)/180VAC-285VAC(230VAC)/190VAC-295VAC(240VAC)
AC input Frequency:45Hz~55Hz(50Hz)，55Hz~65Hz(60Hz)
AC Output
Output Wave:Pure sine wave
Conversion Efficiency:>85%
AC Output Voltage /Frequency Range (lNV Mode):110VAC±2%/220VAC±2%//230VAC±2%/240VAC±2%，50/60Hz±1%
Other
Protection:Battery undervoltage protection/Battery overvoltage protection/Overload power protection/Inverter output short circuit protection/Temperature protection
Protection Degree:IP20
Display:LCD
Cooling Method:Cooling Fan in Intelligent Control
Communication Interfaces:RS485,APP(WIFI monitoring or GPRS monitoring) Optional
Working Mode ( settable ):Battery priority/ Mains priority
Operating Temperature:-15℃~40℃
Relative Humidity:0%~95%，No Condensation
Application
This product can be used Residential,RV Trailer,Emergency Vehicle,Ambulance,Marine,Truck
