Product Attributes
With Toroidal low-loss transformer, high-efficiency inverter conversion,pure sine wave output.
Intelligent LCD display.
Provide adjustable working modes: mains priority,inverter priority.
Optional built-in MPPT solar controller to achieve high-efficiency charging.
Support diesel and gasoline generators, suitable for various grid power.
Support RS485 communication /mobile APP (optional).
OEM/ODM
Aрреаrаnce
Colour
Configurable Data
Technical Parameters
Power
Model:LF 10212/24
Rated Power:1000W
Phase Type:Single phase L-N
Battery
Standard Battery Voltage:12/24VDC
Battery Type:Lead-acid battery/ Lithium battery/Custom battery
Built-in Controller MPPT(optional)
Rated Current:40A/60A
Maximum PV input Power:12V system:40A(560W)/60A(840W),24V system:40A(1120W)/60A(1680W)
Max PV Input Voltage(Voc)(At The Lowest Temperature):120VDC
MPPT Tracking Voltage Range:12V system(15V-80V);24V system(30V-100V)
AC input
Rated Input Voltage:220VAC/230VAC/240VAC
AC Input Voltage Range:145VAC-275VAC(220VAC)/155VAC-285VAC(230VAC)/165VAC-295VAC(240VAC)
AC input Frequency:45Hz~55Hz(50Hz)，55Hz~65Hz(60Hz)
AC Output
Output Wave:Pure sine wave
Conversion Efficiency:>85%
AC Output Voltage /Frequency Range (lNV Mode):220VAC±2%/230VAC±2%/240VAC±2%，50/60Hz±1%
Dimensions and Weight
Product Size (L*w*Hmm):333*253*126
Package Size(L*W*Hmm):423*318*205
N.W.(kg):9
G.W.(kg):10
Application
This product can be used Household,Grassland,Small Power Supply Station,Hill /Island,Environmental Protection,Agricultural Irrigation
