Product Attributes
-With Toroidal low-loss transformer, high-efficiency inverter conversion,pure sine wave output
-Intelligent LCD display.
-The adjustable mains charging current range is 0-20A.
-Provide adjustable working modes: mains priority, inverter priority.
-Optional built-in PWM or MPPT solar controller to achieve high-efficiency charging.
-Support diesel and gasoline generators, suitable for various grid power.
-Support RS485 communication /mobile APP (optional).
OEM/ODM
Aрреаrаnce
Colour
Configurable Data
Product Description
Technical Parameters
Technical Parameters
AC input
Rated Input Voltage:110VAC/120VAC/220VAC/230VAC/240VAC
AC Input Voltage Range:73VAC-138VAC ( 110VAC )/83VAC-148VAC ( 120VAC ) /145VAC-275VAC (220VAC)/155VAC-285VAC ( 230VAC)/165VAC-295VAC(240VAC)(700W-7000W)
92VAC-12BVAC (110VAC)/102VAC-138VAC (120VAC)/185VAC-255VAC (220VAC)/195VAC-265VAC ( 230VAC)/205VAC-275VAC ( 240VAC)( 8KW-40KW )
AC input Frequency:45Hz~55Hz(50Hz)，55Hz~65Hz(60Hz)
AC Output
Output Wave:Pure sine wave
Conversion Efficiency:>85%
AC Output Voltage /Frequency Range (lNV Mode):110VAC±2%/220VAC±2%//230VAC±2%/240VAC±2%，50/60Hz±1%
Other
Protection:Battery undervoltage protection/Battery overvoltage protection/Overload power protection/Inverter output short circuit protection/Temperature protection
Protection Degree:IP20
Display:LCD
Cooling Method:Cooling Fan in Intelligent Control
Communication Interfaces:RS485,APP(WIFI monitoring or GPRS monitoring) Optional
Working Mode ( settable ):Battery priority/ Mains priority
Operating Temperature:-15℃~40℃
Relative Humidity:0%~95%，No Condensation
Application
This product can be used Household,Small Power Supply Station,Grassland,Hill Island,Environmental Protection,Agricultural Irrigation
